Mitsubishi Heavy Industries Ciara 7.1kW Cooling 8.0kW Heating Inverter Split System with WIFI DXK24ZTLA-set

Original price $2,080.00
Original price $2,080.00 - Original price $2,080.00
Original price $2,080.00
Current price $1,950.00
$1,950.00 - $1,950.00
Current price $1,950.00
Model: DXK24ZTLA-WF-SET

Brand new

Availability:
in stock, ready to be shipped

Delivery time & fee

  • Sydney: 3-4 business days; Free.
  • Sydney surrounds: 5-7 business days; Flat rate.
  • Don't ship to: VIC, QLD, NT, SA, WA, TAS.

Overview

The NEW Ciara™ series of split systems incorporates stylish Italian design, with rounded contours and a sleek finish. Compact and lightweight, the Ciara™ series is packed with features including Wi-Fi built-in and Voice control compatibility. Available in reverse cycle models the Ciara™ series is perfect for small to medium spaces.


Model: DXK24ZTLA-WF / DXC24ZTLA-W Inverter: Yes
Capacity-cooling: 7.1 kW Energy star rating-cooling: 3
Capacity-heating: 8.0 kW Energy star rating-heating: 2.5

Dimension (HxWxD mm):Indoor 294x998x230

Dimension (HxWxD mm):Outdoor 640x800x290

In the box: Indoor unit, outdoor unit, remote WiFi: Yes, build-in
Warranty: 5 years


Documents: New Ciara series Intro Flyer.pdf   User Manual.pdf WIFI Set-up Manual.pdf

Feature

BUILT-IN WI-FI

Wi-Fi & voice control now included as standard*. Control your air conditioner anywhere, anytime with your smartphone.

BACKLIT REMOTE CONTROL

Simplified and easier to use remote with backlit screen for dark/night time operation. More accurate temperature control via 0.50C increments.

SILENT MODES

Two levels of silent mode are available to further reduce the outdoor unit noise level.

COMPACT DESIGN

A compact and lightweight design allows for improved installation flexibility and installation into existing or smaller spaces such as apartments.

JET AIR TECHNOLOGY

Air flow is regulated using the same blade technology as that in jet engines which produces powerful, yet efficient air flow.

ALLERGEN CLEAR FILTER

Captures airborne allergens such as hair, pollen and dust particles before neutralising them and any bacteria using specially formulated enzymes.

Specification

Indoor DXK24ZTLA-WF
Outdoor DXC24ZTLA-W
Power Source (Outdoor Unit) 1 Phase, 220 - 240V, 50Hz
Nominal Capacity (Cooling) 7.1 (1.2~7.3) kW
Nominal Capacity (Heating) 8.0 (1.1~9.4) kW
Power Consumption (Cooling) 2.27 (0.28 - 2.67) kW
Power Consumption (Heating) 2.30 (0.26 - 3.42) kW
Maximum Power Consumption 3.76 kW
Running Current (Cooling) 9.6 A
Running Current (Heating) 9.7 A
Inrush Current, Maximum Current 5.0, 17 A
Sound Pressure Level (Indoor) 49-44-39-31 dB(A)
Sound Pressure Level (Outdoor) 55 dB(A)
Energy Rate Cooling 3
Energy Rate Heating 2.5
External Dimensions (Indoor) 294x998x230 mm
External Dimensions (Outdoor) 640x800(+71)x290 mm
Net weight (Indoor) 12 kg
Net weight (Outdoor) 42.5 kg
Airflow indoor cooling 320-253-210-157 l/s
Airflow indoor heating 345-295-243-193 l/s
Refrigerant R32
Refrigerant Amount 1.2 kg
Refrigerant Pre-Charged to Pipe 15 m
Liquid line Ø6.35 mm
Gas line Ø12.7 mm
Connection Method Flare connection
Maximum Pipe Length (One Way) 30 m
Max Vertical Height Diff. Between O.U. and I.U. 20 ( O.U. above I.U. ) / 20 ( O.U. below I.U. )
Standard accessories Allergen Clear Filter x 1, Wi-Fi
Demand Response (AS4755) Yes
